Customizable Asphalt Paver Cement Concrete Slip Form Paver Machine

Customizable Slipform Paver for Asphalt and Cement Concrete Construction

Application range

This equipment can be used in the construction of concrete water-retaining strips and small-end curbs in municipal roads and expressways. Commonly known as asphalt sand forming machine, water barrier forming machine, curb stone slip forming machine, etc. The main components of the machine are composed of diesel engine, reducer, screw rod, hopper, mold, steering and four-wheel height adjustment and other mechanisms.

working principle

A spiral blade is installed in front of the forming mold, and the blade rotates continuously to push materials such as cement or asphalt concrete into the cavity of the mold. After filling the mold space, the concrete material will have a reaction force on the spiral blade. When the reaction force is greater than the machine drive When the force is applied, the machine is driven forward. When the machine is moving forward, the curbstone or water-stop that has been extruded will break away from the rear of the equipment mold and remain on the working surface.

Features

It is suitable for asphalt concrete, dry hard cement concrete and low slump cement concrete.

Curb stones can be paved on the water-stabilized layer, or water-retaining strips or curb stones can be directly paved on the asphalt pavement.

The line shape of the formed structure is smooth and smooth, the color is consistent, and the appearance is more beautiful.

The molded structure is firmly inlaid with the ground, without seams, and has a strong integrity.

The machine has a compact shape and structure, and is easy to move and transition.

Easy maintenance, low failure and loss rate, suitable for long-term construction work.

One machine can replace multiple sets of molds.

Technical Parameters
