1200mm Width Concrete Slip Form Paver 0-3m/Min Slipform Machine

Name: 1200mm Width Concrete Slip Form Paver 0-3m/Min Slipform Machine
Brand: Jiangsu Siming Engineering Machinery Co., Ltd.
SKU: SMC-450
Availability: InStock

Product Details

Place of Origin: Jiangsu, China

Brand Name: SIMING

Certification: ISO9001/CE

Model Number: SMC-450

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Packaging Details: Container shipping

Delivery Time: 30-45 work days

Payment Terms: L/C,T/T

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                1200mm Width Concrete Slip Form Paver, 3m/Min Slipform Machine, 1200mm Width Slipform Machine


Paving Width:	1200mm	Paving Height:	450 Mm
Model:	Customized	Paving Speed:	0-3 M/min
Overall Dimensions:	2400 X 920 X880 Mm	Condition:	New

Paving Width:	1200mm
Paving Height:	450 Mm
Model:	Customized
Paving Speed:	0-3 M/min
Overall Dimensions:	2400 X 920 X880 Mm
Condition:	New

1200mm Width Concrete Slip Form Paver 0-3m/Min Slipform Machine

Versatile Concrete Slip Form Paver for Different Construction Conditions

The slipform machine is mainly composed of parts such as the traveling mechanism, the feeding system, the vibrating system, the forming mold and the control system.

The traveling mechanism provides the moving power for the entire equipment, ensuring that the slipform machine can move steadily along the predetermined route. Its speed can be adjusted according to actual needs to adapt to different construction conditions.

The feeding system is responsible for uniformly transporting the concrete to the forming mold. It usually adopts spiral conveying or other methods to ensure the continuous supply of concrete and make the construction process uninterrupted.

The vibrating system is one of the key parts of the reverse vibrating and extruding slipform machine. Vibrating rods are set in front of the forming mold. Through the high-frequency vibrating effect, the aggregates in the concrete are distributed more evenly, and the bubbles are discharged to achieve a dense effect.

Application Features

Use the reciprocating push hammer to extrude the mixture, which enhances the applicability of the slipform machine to structures of different sizes
Steering, longitudinal and transverse slopes are automatically controlled by high-performance sensors, and the curb line is smoother and the surface is more flat
The operating platform can be rotated and disassembled, which is easy to operate during construction and easy to remove for protection after construction
Only 7 to 8 people are needed to complete the paving work on site (1 person drives, 1 person controls the feeding, 1 to 2 people scrape the surface, 2 people maintain, and 2 people line the steel wire baseline)
It adopts full hydraulic drive, compact structure and convenient maintenance

Technical Parameters

No.	Project	Unit	Parameter
1	Engine	/	Briggs & Stratton 3054 16HP
2	Hydraulic pump	/	G5-5 gear pump
3	Paving speed	m/min	0～3
4	Paving size	cm	Curb stone width 120*height 45
5	Host weight	kg	960
6	Shipping size(LWH)	mm	2400920880
