Used Road Curb Kerb Laying Machine 300mm Paving Width 12.1kw Engine

Product Details

Place of Origin: Jiangsu, China

Brand Name: Siming

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $2,500

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                used road curb laying machine, 300mm paving width slipform paver, 12.1kw engine kerb laying machine


Weight:	2000 Kg	Paving Width:	≤300mm
Paving Thickness:	≤300mm	Engine Model:	Changchai ZS1100
Power:	12.1kw	Rotating Speed:	2200r/min
Screw Speed:	52r/min	Machine Dimensions:	1600x950x1400mm
Hopper Volume:	0.08m3	Spiral Blade Diameter:	φ170mm
Spiral Shaft Diameter:	φ50mm	Spiral Shaft Length:	460mm
Work Efficiency:	6m3/h	Wheel Diameter:	φ190mm
Track Width:	490mm

Weight:	2000 Kg
Paving Width:	≤300mm
Paving Thickness:	≤300mm
Engine Model:	Changchai ZS1100
Power:	12.1kw
Rotating Speed:	2200r/min
Screw Speed:	52r/min
Machine Dimensions:	1600x950x1400mm
Hopper Volume:	0.08m3
Spiral Blade Diameter:	φ170mm
Spiral Shaft Diameter:	φ50mm
Spiral Shaft Length:	460mm
Work Efficiency:	6m3/h
Wheel Diameter:	φ190mm
Track Width:	490mm

Used Road Curb Kerb Laying Machine 300mm Paving Width 12.1kw Engine

SMC-300 Watershed Forming Machine Concrete Cement Road Curb Kerb Laying Machine

Key Specifications

Attribute	Value
Core Components	Engine, hydraulic pump, vibrating spear
Weight	2000 kg
Warranty	1 Year (3 years for core components)
Engine Model	Changchai ZS1100
Power	12.1kw
Paving Width	≤300mm (customizable)
Paving Thickness	≤300mm

UNIQUE SELLING POINT: Low Maintenance Cost

Application Range

This equipment is designed for constructing concrete water-retaining strips and small-end curbs in municipal roads and expressways. Also known as asphalt sand forming machine, water barrier forming machine, or curb stone slip forming machine.

The machine consists of diesel engine, reducer, screw rod, hopper, mold, steering mechanism, and four-wheel height adjustment system.

Technical Parameters

Parameter	Value	Notes
Machine Dimensions (L×W×H)	1600×950×1400mm	Without mold, excludes tow bar
Hopper Volume	0.08m³
Screw Maximum Speed	52r/min
Theoretical Work Efficiency	6m³/h
Walking Wheel Diameter	φ190mm
Track Width	490mm
Wheelbase	1340mm
Climbing Ability	30%

Working Principle

A spiral blade installed in front of the forming mold rotates continuously to push cement or asphalt concrete into the mold cavity. When the material fills the mold space, the reaction force against the spiral blade drives the machine forward. As the machine moves, the extruded curbstone or water-stop separates from the rear of the mold and remains on the working surface.

Key Features

Works with asphalt concrete, dry hard cement concrete, and low slump cement concrete
Can pave curb stones on water-stabilized layers or directly on asphalt pavement
Produces smooth, consistent lines with uniform color and attractive appearance
Forms structures firmly embedded in ground without seams for strong integrity
Compact design for easy movement and transition between work sites
Low maintenance requirements with minimal failures, suitable for long-term projects
Single machine replaces multiple sets of molds

Frequently Asked Questions

What payment terms are accepted?

L/C, T/T, D/A, D/P, Western Union

What certificates are available?

ISO certificate

What is the delivery time?

7-30 days after receiving deposit

What is the warranty period?

12 months after shipment

What is the minimum order quantity?

1 piece
